Model H

The Horizontal model is designed for under-window and low-profile wall applications, delivering high performance in a compact footprint.

Key Features

  • Variable-speed inverter technology
  • Low-profile horizontal configuration
  • Ultra-quiet fan and compressor operation
  • Onboard digital display
  • Washable, long-life filters
  • LCDI plug-in power connection

Controllers

  • Wall-mounted controller
  • Mobile app

Options

  • LCDI plug-in power cord
  • Custom factory colors

Technical Specifications



  • Maximum cooling capacity (kBtu/h)
  • Rated cooling capacity
    (kBtu/h)
  • Minimum cooling capacity (kBtu/h)
  • Rated power
     consumption (kW)
  • EER

400

  • 5.8
  • 5.2
  • 1.0
  • 0.30
  • 17.3

600

  • 10,236
  • 8,837
  • 2,047
  • 500
  • 17.7

800

  • 14.7
  • 12.3
  • 3.4
  • 0.75
  • 16.4



  • Maximum heat output (kBTU/h)
  • Rated heat output (kBTU/h)
  • Minimum heat output (kBTU/h)
  • Rated power
     consumption (kW)
  • COP

400

  • 7.9
  • 7.1
  • 1.4
  • 0.30
  • 6.93

600

  • 12.3
  • 10.6
  • 2.7
  • 0.50
  • 6.20

800

  • 17.1
  • 14.3
  • 3.6
  • 0.75
  • 5.60



  • Voltage (V/ph/Hz)
  • Maximum absorbed current (A)

400

  • 230/1/60
  • 3.87

600

  • 230/1/60
  • 5.01

800

  • 230/1/60
  • 7.5



  • Maximum air flow rate
  • Average air flow rate (CFM)
  • Minimum air flow rate
    (CFM)
  • Nominal air flow rate

400

  • 194
  • 121
  • 59
  • 174

600

  • 294
  • 180
  • 103
  • 259

800

  • 306
  • 253
  • 153
  • 383
