Model V

The Vertical model offers a slim, upright configuration ideal for tight spaces where floor area is limited but performance expectations remain high.

Key Features

  • Variable-speed inverter compressor
  • Vertical, space-saving form factor
  • Quiet operation for residential environments
  • LCDI plug-in power connection
  • Onboard display with intuitive controls
  • Washable filters for simplified maintenance

Controllers

  • Wall-mounted controller
  • Smartphone app integration

Options

  • LCDI plug-in power cord
  • Custom factory colors

Technical Specifications



  • Maximum cooling capacity (kBTU/h)
  • Rated cooling capacity (kBTU/h)
  • Minimum cooling capacity (kBTU/h)
  • Rated power consumption (kW)
  • EER

400

  • 7.2
  • 6.1
  • 1.0
  • 0.30
  • 20.5

600

  • 12.6
  • 10.5
  • 2.1
  • 0.50
  • 20.9



  • Maximum heat output (kBTU/h)
  • Rated heat output (kBTU/h)
  • Minimum heat output (kBTU/h)
  • Rated power
     consumption (kW)
  • COP

400

  • 8.57.2
  • 7.2
  • 1.4
  • 0.30
  • 7.00

600

  • 13.3
  • 10.7
  • 2.7
  • 0.50
  • 6.26



  • Voltage (V/ph/Hz)
  • Maximum absorbed current (A)

400

  • 230/1/60
  • 3.87

600

  • 230/1/60
  • 5.01



  • Maximum air flow rate
  • Average air flow rate
    (CFM)
  • Minimum air flow rate
  • Nominal air flow rate

400

  • 200
  • 124
  • 59
  • 177

600

  • 269
  • 184
  • 103
  • 284
